Journal article
Primary cumulus platinum minerals in the Monts de Cristal Complex, Gabon: magmatic microenvironments inferred from high-definition X-ray fluorescence microscopy
SJ Barnes, LA Fisher, B Godel, MA Pearce, WD Maier, D Paterson, DL Howard, CG Ryan, JS Laird
Contributions to Mineralogy and Petrology | SPRINGER | Published : 2016
Abstract
An unusual occurrence of Pt-enriched pyroxenites in the Monts de Cristal igneous complex is characterized by unusually high ratios of Pt to other platinum-group elements (PGEs) and very low Cu and sulfide contents. Synchrotron X-ray fluorescence microscopy was used to identify over a hundred discrete grains of platinum minerals and relate their occurrence to textural associations in the host heteradcumulate orthopyroxenites. Element associations, backed up by FIB-SEM and PIXE probe observations, indicate that most of the Pt is associated with either As- or trace Cu–Ni-rich sulfides, or both. Some of the Pt–As grains can be identified as sperrylite, and most are likely to be Pt–Fe alloy. The ..
View full abstractGrants
Funding Acknowledgements
This research was carried out on the X-ray fluorescence microscopy beam line at the Australian Synchrotron, Clayton, Victoria, Australia. We acknowledge financial support for this facility from the Science and Industry Edowment Fund (SIEF). We thank Martin de Jonge for his programming of complex scan control scripts and Kathryn Spiers for beamline assistance during the experiment. James Mungall provided helpful reviews of a preliminary draft. This work was supported by the Multi-modal Australian ScienceS Imaging and Visualisation Environment (MASSIVE) (www.massive.org.au). We acknowledge the support of the National Resource Sciences Precinct through the Advanced Resource Characterisation Facility for access to the FIB-SEM. We thank David Holwell, Raul Fonseca and Associate Editor Christian Ballhaus for helpful and constructive reviews that greatly improved the final paper.
